Automatic Destacker PCB Handling Machine for High Volume Production with 6S PCB Load

ब्रांड नाम:	Winsmart
मॉडल संख्या:	एसएमटीडीएसए-250
मूक:	1 इकाई
कीमत:	USD1-50000/unit
पैकेजिंग विवरण:	प्लाईवुड मामले
भुगतान की शर्तें:	टी/टी

विस्तृत जानकारी

उत्पाद वर्णन

विस्तृत जानकारी

उत्पत्ति के प्लेस:

प्रमाणन:

पीसीबी लोड:

6S के बारे में

पावर लोड:

अधिकतम आपूर्ति 600VA तक

कुल वजन:

200kgs

गुणवत्ता:

उच्च गुणवत्ता और 100% परीक्षण

आयाम:

L900*W830*H1200 मिमी

दिशा:

एलआर/आरएल

मशीन का आयाम:

600（L）*800（W）*1250（H）mm

प्रकार:

पीसीबी हैंडलिंग मशीन

आपूर्ति की क्षमता:

500 यूनिट/माह

प्रमुखता देना:

High Volume Production PCB Handling Machine

Automatic Destacker PCB Loader Unloader

6S PCB Load Automatic Destacker

उत्पाद वर्णन

PCB Handling Machine Automatic Destacker

Automatic destacker for high-volume PCB production lines, designed to separate stacked PCBs and feed them into subsequent assembly processes with precision and efficiency.

Product Overview

The Automatic Destacker is a specialized PCB handling machine that automatically separates stacked printed circuit boards in a controlled manner. This equipment is essential for high-volume production lines where consistent automated handling maintains efficiency and reduces human error.

Key Features

Product Name: PCB Loader Unloader

Marketing Type: SMT Production Line Equipment

Function: PCB Transportation

Delivery: Within 7 Days After Payment

Power: 220/110V

Direction: L-R / R-L

Technical Specifications

Attribute	Value
Direction	L-R / R-L
Gross Weight	200kgs
Power	220/110V
Marketing Type	SMT PCB Production Line
Power Load	Supply Max. To 600VA
Dimension	L900W830H1200mm
Unloading Method	Automatic
Quality	High Quality And 100% Tested
Type	SMT Machine Parts
Delivery	Within 7 Days After Payment

Primary Functions

The automatic PCB destacker separates individual PCBs from stacks and feeds them into subsequent assembly stages including:

Inspection stations
Component placement (SMT and through-hole)
Soldering processes (wave soldering, reflow soldering)
Testing and quality control

This equipment ensures careful handling without damage, provides continuous automated PCB supply, and reduces manual labor costs.

Working Principle

Stack Loading: Stacked PCBs are loaded onto input tray or conveyor system
Sensing: Optical or mechanical sensors detect stack and ensure proper alignment
Feeding Mechanism: Mechanical/robotic arm or rollers grab top PCB from stack
Destacking Process: Precise separation of top PCB without damage or sticking
Orientation and Alignment: Automatic positioning to match required orientation
Continuous Feed: Seamless destacking and feeding into production line

Support and Services

Installation and setup guidance for proper equipment installation
Operator training for effective and efficient product use
Ongoing technical support for operational questions and concerns
Maintenance and repair services for peak performance
Upgrades and updates with latest technology and features
